Ada and Grace, the ArticuLab's virtual peer tutoring agents

CMU ArticuLab · Advisor: Alexandros Papangelis 2014

Understanding Intentions and Social Goals behind User Behavior

Understanding the social signals that indicate friendship — and training a machine to read them from video.

Abstract

Rapport between two strangers is established over time through the use of conversational strategies. For example, a person might reveal something personal about herself, which would then transition the conversation from the polite to the intimate.

This project aimed to determine if participants in a peer tutoring setting were friends from video, voice transcripts, and manual video annotations. For the final deliverable, I built a classifier that could determine friendship with high accuracy using 28 different features extracted from these sources.

Context

The ArticuLab at Carnegie Mellon studies how two people in a dyadic setting create, maintain, and break rapport. The end goal: a virtual peer tutor that can build genuine rapport with a student — knowing when to push, when to ease off, and when the relationship has warmed enough to try something harder.

My contribution was a specific subproblem: can a classifier detect whether two people are friends from video of them peer tutoring together? Friendship is a strong prior indicator of rapport, and detecting it automatically would let the tutoring agent calibrate its social strategy from the start of a session.

Literature Review

I began with a survey of existing research in rapport, nonverbal behavior, and social signal processing. The key nonverbal features that distinguished pairs with established rapport: smiling frequency, head nods, head shakes, and eye gaze patterns.

Stack of printed research papers with handwritten annotations about rapport indicators — Literature survey — mapping the nonverbal features most consistently linked to rapport and friendship in peer interaction research.

I also consulted a project member specializing in verbal behavior to identify conversational strategies — specific phrasings and patterns in transcripts that signal intimacy, disclosure, and alignment.

Feature Extraction

I developed a toolkit to extract features from three sources:

Video: using my Modified FaceTracker from the senior thesis to extract smile frequency, head position, and head movement for each participant
Transcripts: NLP-based extraction of rapport-related conversational strategies (self-disclosure, topic reciprocation, hedging)
Manual annotations: frame-level behavioral tags from the ArticuLab annotation protocol

The FaceTracker gave me continuous emotional state estimates and head kinematics across each tutoring session — the same engine I had built and validated in my thesis work.

Face mesh overlay on a participant expressing surprise — points tracked across forehead, eyes, nose, and mouth — The Modified FaceTracker outputting a facial mesh. Used here to extract smile frequency, head position, and head movement across each tutoring session.

Classifier

I trained an SVM classifier on 28 extracted features, iterating on the feature set until detection accuracy was high on held-out sessions. The final model could determine whether two participants were friends from a tutoring video with strong accuracy — providing the rapport agent with a useful social prior before a session’s first exchange.

Role

Sole researcher and developer on the detection component. Supervised by Alexandros Papangelis. Built the feature extraction pipeline, adapted the FaceTracker for multi-person dyadic video, and trained and evaluated the final classifier.
